G100-1L is a industrial peristaltic pump for controlled liquid handling in industrial and production workflows. Review its operating range and compatibility for your process.
| Parameter | Value |
|---|---|
| Max. flow rate(Single Channel) | 750 mL/min |
| Pump speed | 0-150rpm, CW/CCW |
| Speed resolution | 0.01rpm(＜10rpm); 0.1rpm(10rpm≤speed＜100rpm) |
| Housing material | Die-cast aluminum |
| Display | LCD for speed, flow rate, volume and other parameters |
| Work mode | Continuous mode; Time mode; Volume mode |
| Control mode | Keypad control; Footswitch control; External control; Communication control |
| Calibration function | Flow rate calibration; Volume calibration |
| External control | Control function: start/stop, running direction, speed |
| Communication control | RS485, Modbus RTU |
| Dimensions (L x W x H) | 240×142×152(mm) |
| Power supply | AC100-240V, 50/60Hz |
Confirm the required operating range, fluid path and compatible configuration for this industrial peristaltic pump with ProfTek before final selection.
Manufactured by Longer Pump. ProfTek supplies and supports Longer Pump products across Australia and New Zealand.
