PH600-2 is a industrial peristaltic pump for controlled liquid handling in industrial and production workflows. Review its operating range and compatibility for your process.
| Parameter | Value |
|---|---|
| Speed range | 150rpm-600rpm (unstable below 150rpm) |
| Running direction | CW or CCW (controlled via a direction control valve) |
| Control type | Manual control Stepless speed control via a throttle valve Start/stop & direction control via a direction control valve |
| Display | Pressure gauge on the air treatment unit (FR unit) indicates the supply air pressure. |
| Rated air supply pressure | 0.6MPa |
| Maximum air consumption | 4.4L/s |
| Housing material | Stainless steel |
| Air supply tubing | ID*OD 12x8mm PU |
| Overload protection | Motor slows or stops during overload and resumes automatically when cleared |
| Environment temperature | 0-60℃ |
| Dimensions(LxWxH) | 478*243*301(mm) |
| Weight | 18 kg |
Confirm the required operating range, fluid path and compatible configuration for this industrial peristaltic pump with ProfTek before final selection.
Manufactured by Longer Pump. ProfTek supplies and supports Longer Pump products across Australia and New Zealand.
